Basic Parameters
Height: 163.82mm
Width: 76.54mm
Depth: 8.9mm
Weight: 230g
Metal: Middle Frame + Corning Glass Rear Cover
Color: Subzero, Nightfreeze
Memory Combination: Nightfreeze: 12 + 256GB / 16 + 512GB, Subzero: 16 + 512GB
LPDDR5X Ultra + UFS 4.1
Dust and Water Protection: IPX8* Rating Water Resistance with Unique Dust-Proof Design
Display
Size: 6.85 Inch BOE X10 FHD+
Refresh Rate: Up to 144Hz
Touch Sampling Rate: Highest 3000 Hz, Multi-Finger 360Hz
Resolution: 2688x1216 Pixels
Aspect Ratio: 20:9
Type: AMOLED
Peak Brightness: 1,800 Nits Max
Material: Corning® Gorilla® Glass
Color Gamut: 100% DCI-P3
Color Accuracy △E＜1
Cooling System
Revolutionary REDMAGIC AquaCore Cooling System
Under-Screen Copper Foil
Under-Screen High-Conductivity Graphene
13,116 mm² Large Vapor Chamber
Composite Liquid Metal 3.0
Aircraft Grade Aluminum Alloy Mid-frame
High-Thermal-Conductivity Gel
Upgraded 24,000 RPM Waterproof Turbo Fan
Motherboard Copper Foil
High-Speed Aerospace Aluminum Air Duct
Flowing Liquid Cooling
Hardware
Snapdragon 8 Elite Gen 5 Leading Version
CPU: 2+6 Oryon™ architecture
CPU Frequency: up to 4.74 GHz
GPU: Adreno™
RedCore R4
Capacity*
RAM: 12GB / 16GB LPDDR5X Ultra
ROM: 256GB / 512GB UFS 4.1
*Actual memory space is less and varies due to many factors
Connectivity
Network
SIM: Dual nano-SIM(Not support e-sim)
5G Network
Modes: SA (Standalone) & NSA (Non-Standalone)
5G Bands (NR): n1 / 2 / 3 / 5 / 7 / 8 / 20 / 26 / 28 / 38 / n40 / n41 / 66 / n77 / n78
4G LTE
TDD: B34 / 38 / 39 / 40 / 41 / 42
FDD: B1 / 2 / 3 / 4 / 5 / 7 / 8 / 12 / 17 / 18 / 19 / 20 / 26 / 28 / 66
3G
UMTS B1 / 2 / 4 / 5 / 6 / 8 / 19
2G
GSM 2 / 3 / 5 / 8
Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
Tri-band (2.4GHz / 5GHz / 6GHz)
Features: HBS (High Band Simultaneous) Support
Bluetooth: Bluetooth 5.4
GPS: Dual GPS (L1+L5)
NFC: Yes
HDMI: Converter Needed
DP, Supports 4K HD Video
Cameras
Rear Camera
Resolution: 50MP+50MP+2MP
Sensor:
OV50E40, 1/1.55, 7P F1.88
OV50D40, 1/2.88, 6P F2.0
OIS Optical Image Stabilization
7P Lens
APL-coated Anti-glare
Front Camera
Resolution: 16MP, AI Algorithm Enhancement
Sensor:
OV16A, 1/2.77, 5P, F2.0
Sensors
3D Ultrasonic Fingerprint Sensor, Accelerometer, Electronic Compass, Gyroscope, Proximity Sensor, Ambient Light Sensor, Infrared Sensor
Biometric Authentication
Fingerprint Recognition, Face Recognition
Operating System
REDMAGIC OS 11.5 Based on Android 16.0
Battery & Quick Charger
Battery: 7,500mAh (Single Cell)
Wired Fast Charging: 80W
Wireless Fast Charging: Supports up to 80W
Supports Wired and Wireless Reverse Charging
Ports
Ports: USB 3.2 Gen 2, Type-C, DP, Dual Nano-SIM Slot, 3.5mm Audio Jack
Audio Supported Formats
Playback: WAV, AAC, MP3, AMR, FLAC, OGG, APE
Recording: MP3
1015 +1115e Stereo Speakers
Video Supported Formats
Playback: 3GP, ASF, AVI, FLV, M2TS, MKV, MOV, MP4, MPG, MTSTS, WEBM, WMV, MPEG, M4V
Recording: MP4
Image Supported Formats
Playback: JPEG, PNG, GIF, BMP, WBMP, HEIC
Output: JPEG
Special Functions
Shoulder Trigger Buttons: 520Hz Touch Sampling Rate Touchpads
Haptics: 0815 X-axis Linear Motor
Magic Key: By default, it launches the GameSpace, but users can customize it for quick access to other functions such as taking photos or recording videos with the rear camera, enabling the flashlight, launching the voice recorder, or switching to mute or vibration mode.
RGB Light: Fully customizable lighting effects. Adds a new side-frame RGB light strip, while retaining the fan, shoulder triggers, and logo lights.
What's in the box
REDMAGIC 11S Pro Phone x 1
Semi-transparent Phone Case x 1
Power Adapter x 1
Type-C Data Cable x 1
SIM Tray Ejector x 1
Warranty Card x 1
User Manual x 1
Disclaimer：
1. Devices were tested under controlled laboratory conditions and achieved an IPX8 rating. The air duct adopts an independent cooling structure; dust may enter this duct during operation but it does not affect the device’s core functions or overall performance under normal use. Please note that splash, water, and dust resistance are not permanent features, and normal wear and tear may reduce their effectiveness. Please do not charge the device when it is wet.
2. Data regarding the REDMAGIC display’s narrow bezel dimensions, screen size, device width, weight, thickness, and other related measurements is sourced from official laboratory testing. Actual results may vary due to differences in color variants, testing environments, testing methods, manufacturing processes, and other factors. Please refer to the actual product.
3. All data, including cooling performance, charging speed, and other performance-related information, is based on testing conducted by REDMAGIC Internal Labs under specific test conditions, as described in each relevant section. Actual performance may vary due to differences in individual products, software versions, usage conditions, and environmental factors. Please refer to actual usage experience. Actual results may vary.
4. The 7,500mAh capacity refers to the typical battery capacity of the REDMAGIC 11S Pro. Actual battery life may vary depending on the network environment, features and apps used, call and message frequency, charging habits, and other factors.
5. Part of the device storage is occupied by system software, including the Android operating system and pre-installed apps. Therefore, the available storage capacity is lower than the stated storage capacity. Available storage may vary depending on the software version and may differ between devices.
6. Game-in high refresh rate performance (e.g. 120Hz) may vary depending on the optimization progress of different games, and related capabilities may still be in a gradual rollout or adaptation phase. Due to differences in game versions and regional package strategies, actual support may vary, and final performance is subject to in-game conditions.
7. Photo resolution may vary across different shooting modes. Video resolution may also vary across different recording modes. Please refer to actual results.
